"JetStream™ 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ PORT: 24× 2.5G RJ45 Ports (8× 2.5G PoE++ Ports & 16× 2.5G PoE+ Ports), 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 802.3bt/at/af, 500 W PoE
5.975,00 RON
(TVA inclus)
Livrare 1-3 zile lucratoare
Cost livrare - 25 lei
Cum te putem ajuta?
Descriere
"JetStream™ 24-Port 2.5GBASE-T and 4-Port 10GE SFP+ L2+ Managed Switch with 16-Port PoE+ & 8-Port PoE++ PORT: 24× 2.5G RJ45 Ports (8× 2.5G PoE++ Ports & 16× 2.5G PoE+ Ports), 4× 10G SFP+ Slots, RJ45/Micro-USB Console Port SPEC: 802.3bt/at/af, 500 W PoE Power, 1U 19-inch Rack-mountable Steel Case FEATURE: Integration with JetStream™ SDN Controller, Static Routing, OAM, DDM, 802.1Q VLAN, QinQ, STP/RSTP/MSTP, IGMP Snooping, 802.1p/DSCP QoS, ACL, 802.1x, Radius/Tacacs+ Authentication, LACP, CLI, SNMP, Dual Image/Configuration, IPv6"
Detalii
SKU
TL-SG3428XPP-M2
Categorii
Brand
Sustainability compliance
Yes
Operating relative humidity (H-H)
10 - 90%
Cables included
AC
Password protection
Yes
Storage relative humidity (H-H)
5 - 90%
Operating temperature (T-T)
0 - 40 C
LED indicators
Yes
Quick start guide
Yes
AC input voltage
100 - 240 V
Number of fans
3 fan(s)
Depth
330 mm
Compliance certificates
CE, Federal Communications Commission (FCC), RoHS
Storage temperature (T-T)
-40 - 70 C
Web-based management
Yes
Multicast support
Yes
Redundant power supply (RPS) support
Yes
Rack mounting
Yes
Redundant fans support
Yes
Rack mount kit
Yes
Rackable
Yes
System event log
Yes
Jumbo frames support
Yes
VLAN support
Yes
Rate limiting
Yes
Switch layer
L2+
Spanning tree protocol
Yes
Port mirroring
Yes
Power over Ethernet (PoE)
Yes
Link aggregation
Yes
Power supply included
Yes
IGMP snooping
Yes
Loop protection
Yes
Store-and-forward
Yes
Stackable
No
Flow control support
Yes
Switch type
Managed
Broadcast storm control
Yes
Static route
Yes
Jumbo frames
9000
MAC address table
32000 entries
Quality of Service (QoS) support
Yes
Cloud-managed
Yes
Configuring Location Settings (CLI)
Yes
ARP inspection
Yes
SFP+ module slots quantity
4
Basic switching RJ-45 Ethernet ports quantity
24
SFP module slots quantity
4
Access Control List (ACL)
Yes
SSH/SSL support
Yes
LAN-Ports
24
Layer
Layer-2
LAN-Port-Type
Gigabit
Redundant-PSU
Yes
Installed SFP+ modules quantity
0
Installed SFP modules quantity
0
Static port security
Yes
Full duplex
Yes
Flash memory
32 MB
Number of queues
8
Half duplex
Yes
GARP VLAN Registration Protocol (GVRP)
Yes
BPDU filtering/protection
Yes
IP-MAC-Port binding
Yes
10G support
Yes
MIB support
RFC1213, RFC2233, RFC1643, RFC1493, RFC2674, RFC2819, RFC2021, RFC2620, RFC2618, RFC2925
IPv4 routes
48
IPv6 routes
48
2.5G Ethernet (copper) ports quantity
24
Power source
AC/PoE
Power over Ethernet plus (PoE+) ports quantity
16
Basic switching RJ-45 Ethernet ports type
2.5G Ethernet (100/1000/2500)
Head-of-line (HOL) blocking
Yes
Power over Ethernet 4PPoE (PoE++) ports quantity
8
Number of static routes
48
Console port
RJ-45/micro-USB
DHCP features
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 snooping
Security algorithms
HTTPS, SSH, SSH-2, SSL/TLS
Queue scheduling algorithms
SP, WRR+SP, Weighted Round Robin (WRR)
Forwarding rate
148.8 Mpps
Packet buffer memory
16 MB
Switching capacity
200 Gbit/s
Authentication
Guest VLAN, MAC-based authentication, Port-based authentication
Number of IP interfaces
32
Ethernet LAN data rates
10,100,1000,2500,10000 Mbit/s
Multicast Listener Discovery (MLD) snooping
MLD v1/v2
Virtual LAN features
MAC address-based VLAN, Port-based VLAN, Protocol-based VLAN, Stacked VLAN, Tagged VLAN, Voice VLAN
Heat dissipation
2153.45 BTU/h
Power consumption (max)
629.1 W
Total Power over Ethernet (PoE) budget
500 W
IPv4 & IPv6 features
IPv4/IPv6 access-control list (ACL), IPv6 ping, IPv6 portal, IPv6 tracert
Authentication type
AAA, IEEE 802.1x, RADIUS, TACACS+
Management protocols
SNMP v1, v2c, v3
Form factor
1U
Memory type
DRAM
