NOU
Placa de baza Gigabyte B760 DS3H, LGA 1700, DDR4, ATX
638,00 RON
(TVA inclus)
Livrare 1-3 zile lucratoare /
Cost livrare - 25 lei
Cum te putem ajuta?
Descriere
Placa de baza Gigabyte B760 DS3H DDR4 LGA1700 DDR4, 4x sloturi ram, max. 128GB, frecventa maxima suportata 5333MHz, 1x DisplayPort, 1x HDMI, 5x PCIe x16, 2x M.2, 4x conectori SATA 6GB/s, 1x LAN 1Gbps, ATX
Detalii
SKU
B760 DS3H DDR4
Categorii
Brand
Processor manufacturer
Intel
Ethernet LAN
Yes
HDMI ports quantity
1
Memory channels
Dual-channel
Maximum internal memory
128 GB
Component for
PC
Microphone in
Yes
USB 3.2 Gen 2x2 Type-C ports quantity
1
HDMI version
2.0
HDCP
Yes
DisplayPorts quantity
1
VGA (D-Sub) ports quantity
0
Wi-Fi
No
DisplayPort version
1.2
Country of origin
China
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity
0
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity
0
USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity
0
USB 2.0 ports quantity
4
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity
1
Battery weight
3 g
Lithium weight per battery
0.07 g
Number of battery cells
1
Battery technology
Lithium-Manganese Dioxide (LiMnO2)
Battery type
CR2032
ACPI version
5.0
Desktop Management Interface (DMI) version
2.7
System Management BIOS (SMBIOS) version
2.7
BIOS type
UEFI AMI
Clear CMOS jumper
Yes
Motherboard form factor
ATX
PC health monitoring
Fan, Temperature, Voltage, Water cooling
Windows operating systems supported
Windows 10 x64, Windows 11 x64
Audio output channels
7.1 channels
Parallel processing technology support
Not supported
DirectX version
12.0
Front panel connector
Yes
TPM connector
Yes
RGB LED pin header
Yes
12V power connector
Yes
USB 3.2 Gen 1 (3.1 Gen 1) connectors
2
Serial port headers
1
USB 3.2 Gen 2 (3.1 Gen 2) connectors
0
Number of SATA III connectors
4
Front panel audio connector
Yes
ATX Power connector (24-pin)
Yes
CPU fan connector
Yes
EPS power connector (8-pin)
Yes
Number of memory slots
4
Memory slots type
DIMM
Unbuffered memory
Yes
Ethernet interface type
Gigabit Ethernet
Package width
335 mm
Package depth
270 mm
Package height
80 mm
DVI-D ports quantity
0
Supported storage drive types
HDD & SSD
Number of HDDs supported
4
RAID support
Yes
Height
35 mm
BIOS memory size
128 Mbit
Number of M.2 (M) slots
2
Motherboard chipset family
Intel
USB 2.0 connectors
2
S/PDIF out connector
Yes
ECC сompatibility
ECC & Non-ECC
Processor socket
LGA 1700
Supported processor sockets
LGA 1700
Number of storage drives supported
6
RAID levels
0, 1, 5, 10
PS/2 ports quantity
1
Supported storage drive interfaces
M.2, PCI Express 4.0, SATA III
Supported memory types
DDR4-SDRAM
Cables included
SATA
Maximum resolution
4096 x 2304 pixels
Total number of SATA connectors
4
USB connector type
USB Type-A, USB Type-C
Headphone outputs
3
Package weight
1.31 kg
Motherboard chipset
Intel B760 Express
Maximum internal memory supported by processor
128 GB
Supported memory clock speed (max)
5333 MHz
Depth
24.4 mm
Width
30.5 mm
PCI Express x16 slots
5
Supported memory module capacities
1GB, 2GB, 4GB, 8GB, 12GB, 16GB, 32GB
Bundled software
Norton Internet Security
PCI
0
Serial-or-Paralel
No/No
Onboard-CPU
No
