SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY INTEGRATED, 4 x IEC 320 (C13), RS232 – USB – Contact de releu,Card opțional NET VISION (TCP/IP și SNMP)
1.860,00 RON
(TVA inclus)
Livrare 1-3 zile lucratoare /
Cost livrare - 25 lei
Cum te putem ajuta?
Descriere
SOCOMEC ITYS 1000VA VFI UPS 1/1 PF=1 WITH BATTERY INTEGRATED
- Embedded dry-contact interface.
- Input mains switch breaker.
- Connection for battery extension modules.
- Power off the UPS remotely.
- Internal temperature sensor.
Input connection C14
Number of output connections C13 4 pcs
Detalii
SKU
ITY3-TW010B
Categorii
Brand
LED indicators
Yes
ECO mode
Yes
Country of origin
China
Display type
LCD
Operating temperature (T-T)
0 - 45 C
RS-232 ports
1
International Protection (IP) code
IP20
Battery technology
Sealed Lead Acid (VRLA)
Control type
Buttons
Output frequency
50/60 Hz
Output operation voltage (max)
240 V
Output power capacity
1 kVA
UPS topology
Double-conversion (Online)
Input frequency
40 - 70 Hz
Crest factor
3:1
Waveform
Sine
Noise level
50 dB
Operating relative humidity (H-H)
0 - 95%
AC outlet types
C13 coupler
Power plug
C14 coupler
USB port type
USB Type-B
Battery capacity
7 Ah
Emergency Power Off (EPO)
Yes
Number of input phases
1
Number of output phases
1
Efficiency (ECO mode)
98%
Safety
IEC/EN 62040-1, AS 62040.1.1, AS 62040.1.2
AC outlets quantity
4 AC outlet(s)
Output power
1000 W
Input power factor
0.99
Output power factor
1
Input operation voltage (max)
300 V
Input operation voltage (min)
160 V
Battery life (max)
3 year(s)
Output operation voltage (min)
200 V
Weight
14.4 kg
Charging current
8 A
Certification
IEC/EN 62040-2, AS 62040.2
IEC/EN 62040-3
CE, RCM (E2376)
Product colour
Black, Grey, Orange
Efficiency
93%
Power protection features
Short circuit
Operating altitude
0 - 1000 m
Typical backup time at full load
7.8 min
Battery voltage
3.6 V
Height
22.4 mm
Width
14.5 mm
Depth
40.4 mm
Form factor
Mini Tower
